Stiltz Duo Home Lift

The intelligent technology and extensive safety features within a Stiltz Duo+ Home Lift makes owning this compact home lift a delight. Suitable for one or two people, the Duo+ has clear sides and a soft, warm grey finish meaning it will compliment both classic and contemporary interiors.

A Stiltz Duo+ Home Lift can typically be installed in a day, once any building work has been completed. You will be delighted with how easy it is to use. Like all our models, a Stiltz is freestanding and does not need a load bearing wall for support. This means no loud vibrations, just smooth and quiet travel from floor to floor.

Learn more about the Stiltz Duo+

The Duo Specifications

Standard Finishes Duo+: pale warm grey construction with clear polycarbonate lift car body. Duo Classic: neutral cream exterior and door with a matching beige interior lining colour.
Half Height Door The door is interlocked and is made to match the finish of the lift.
2 X Remote Controls Call and send the lift remotely and also use it to move heavy or awkward items between floors.
One Year Warranty All Stiltz Lifts carry a compehensive 12 months parts and labour warranty which includes 1st year’s service. Maintenance packages available at extra cost.
Internal LED Downlights These are programmed to turn on once the user has entered the lift and remain on for the entire journey.
Battery Back Up System If there is a power cut while using the lift it will descend to the lower level of the home and wait until the power comes back on.
Full Height Light Curtain Light Curtain is fitted with a half height door.
Interior Telephone In the very unlikely event that the lift stops while you are travelling in it, help is just a phone call away.

Fold Down Seat This is a popular option selected by customers for the short trip between floors.
Interior Grab Rail Offers increased security for the occupants of the lift.
Full Height Door An interlocked door that replaces the half-height door and light curtain.
Bespoke Colours & Finishes Customise your Stiltz lift by choosing different colour lift car, rails and interior lining (Classic range only).
Uninterruptible Power Supply This system will allow for numerous trips both up and down whilst the main power to the lift is out.

Full Height Light Curtain A full-height motion sensor is situated at the entrance of our lifts (unless a full height door is chosen). If this barrier is crossed the lift will immediately stop.
Safety Lid Plug This crucial feature plugs the aperture in the floor when the lift is in the downstairs position. It is strong enough to stand on and you can place your original flooring on top to blend in.
Key Switch Operation This feature allows the owner to isolate the lift if the need arises. This is commonly used when going away on holiday or when the grandchildren are around.
Top & Bottom Safety Pans Using our obstruction sensing covers, a Stiltz Lift can detect objects above or below the lift, causing it to immediately stop.
Hold-To-Run Controls Operating a Stiltz Lift requires constant pressure to the controls. This allows the user to ‘drive’ the lift and feel in total control.
Weight Limit Sensors Our Duo Lifts are limited to 170Kg, 27 stone/ 375lbs. The lift detects anything exceeding this limit and will not travel.
Out Of Balance Sensors Sensors will detect if the lift is ever out of balance and prevent the unit from travelling.
Fall Arrest Mechanism This patented system prevents the car from falling in the unlikely event of the steel ropes going slack.
Emergency Stop Button This button is front and centre for the user in the event of an emergency.
Over Speed Detection The lift uses an optical sensor to detect the speed of travel. If this increases beyond a certain speed, the sensor will stop the lift from travelling in that direction.

Stiltz lifts are inherently simple in design and concept but if you wish to dig a little deeper, you can download all the information you need below.

Drive	Roped drum, braked gear motor drive
Power Supply	220 – 240v AC \| 5 Amps
Maximum Load	170kg \| 27st \| 375lb (2 persons standing or 1 person sitting)
Maximum Travel	3.6 Metres
Entrance Security	Full height light curtain / motion sensor – optional full height door
Maximum Speed	15cm / Second
Warranty	12 months parts and labour warranty
Compliance	European Machinery Directive 2006 / 42 / EC & Australian Standard 1735 Part 15
Rope Diameter	6mm Galvanized steel rope
Additional Sensors	Out-of-balance & overload, overspeed detection and light curtain
Lighting Type	2 x 3w LED downlights
Landing Call Stations	2 Wireless remote control units – call / send facility (3 x standard aaa batteries in each)
Installation	Typical installation takes two days
Operation	Hold-to-run controls
Configuration	Single entry
